Surface Roughness Ra to Rz Calculator

Surface Roughness Ra to Rz Calculator

Convert Ra, Rz, Rt, and RMS values using process-specific roughness ratios, material adjustment, tolerance bands, finish class, cutoff length, and machining process.

1Finish and process presets
2Roughness conversion inputs

Conversions are engineering estimates. Exact Ra/Rz/Rt relationships depend on the measured profile, filter, cutoff, stylus, sampling length, and the specification standard used on the drawing.

Converted surface finish values

Calculated Ra
1.60
um average roughness
Estimated Rz
8.00
um peak-to-valley
Estimated Rt
11.20
um total height
RMS / Rq
1.78
um root mean square
Finish class
N7
ISO 1302 nearest class
Tolerance band
1.44-1.76
Ra allowed range
3Material and spec grid
5.0x
Rz to Ra factor
7.0x
Rt to Ra factor
N7
Matched finish class
OK
Spec suitability
4Process conversion factors
Machining process Typical Ra range Rz/Ra factor Rt/Ra factor Common use
Face milling0.8-6.3 um4.8-5.86.5-8.0Plate faces, pockets
Finish turning0.4-3.2 um4.5-5.56.0-7.5Shafts, shoulders
Cylindrical grinding0.1-0.8 um5.5-6.87.5-9.0Bearing journals
Honing0.1-0.6 um6.0-7.58.0-10.0Cylinder bores
Lapping0.025-0.2 um4.0-5.55.5-7.0Gauge and seal faces
Wire EDM skim0.4-2.5 um5.0-6.57.0-9.5Tooling profiles
5Finish class reference
ISO class Ra um Ra microinch Approx Rz um Typical process
N10.02510.1-0.2Superfinish, polish
N20.0520.2-0.3Lapping, fine polish
N30.140.5-0.7Lapping, fine grinding
N40.281.0-1.3Fine grinding
N50.4162.0-2.8Grinding, honing
N60.8324.0-5.6Fine turning, reaming
N71.6638-11Turning, milling
N83.212516-22General machining
N96.325032-44Rough machining
N1012.550063-88Rough cuts, cast cleanup
6Material/spec suitability grid
Material or spec Common target Ra Process note Inspection note
Aluminum 6061/70750.8-3.2 umMills and turns cleanly with sharp toolsAvoid built-up edge before measuring
Mild steel0.8-3.2 umTurning and milling match common shop specsOil and burrs can skew trace
Stainless steel0.4-1.6 umPolish or fine finish pass often neededCheck torn peaks after work hardening
Hardened tool steel0.1-0.8 umGrinding, EDM skim, lappingUse correct cutoff for fine texture
Cast iron1.6-6.3 umPorosity and graphite affect valleysAverage multiple traces
Seal face0.2-0.8 umGround, lapped, or polishedConfirm direction of lay on the print
Bearing journal0.2-0.4 umCylindrical grinding or superfinishCheck waviness separately
Hydraulic bore0.1-0.4 umHoned plateau finishRa alone may miss valley volume
7Named finish/process presets
Preset Known value Material Expected class Typical application
Face milled plateRa 3.2 umAluminumN8Fixture plates and covers
Finish turned shaftRa 1.6 umMild steelN7General shafting
Ground bearing journalRa 0.4 umTool steelN5Bearing seats
Honed cylinder boreRz 2.8 umCast ironN5Hydraulic and engine bores
Lapped gauge faceRa 0.05 umTool steelN2Gauges and flat references
Polished stainlessRMS 0.28 umStainlessN4Food and cosmetic surfaces
Reamed precision boreRa 0.8 umBrassN6Bushings and dowel bores
Wire EDM skim cutRz 8.0 umTool steelN7Punches and dies
Cast face machiningRt 50 umCast ironN9Machined cast pads
Blanchard ground faceRa 1.2 umMild steelN6/N7Large flat plates
Tip: When a drawing gives only Ra but the inspection report gives Rz, convert with the process family first, then judge the result against the tolerance band and finish class.
Tip: For sealing, sliding, and fatigue surfaces, do not rely on Ra alone. Rz and Rt expose isolated peaks and valleys that Ra can average away.
Safety note: Surface finish estimates do not replace print requirements or certified inspection. Deburr sharp peaks, clean the surface before probing, and confirm critical seal, bearing, fatigue, or pressure-retaining finishes with a calibrated profilometer and the specified cutoff.

A bearing will run cool. A hydraulic valve will seal. An aerospace part make it through its first flight.

You’d expect all these functions is driven by something more than surface finish. But that’s what defines success. Polishing a seal face too smooth remove the valleys that hold oil. Turning a shaft too rough create minute stress risers.

What Ra, Rz, Rt and RMS Mean

Four numbers tell the story: Ra, Rz, Rt and RMS. They’re four numbers that sound interchangeable, yet describe different characteristics on the same surface, the difference between a warranty claim and functional success.

The Arithmetic Average is Ra. It is simple to calculate. Tells you average depth of your valleys and hills. Doesn’t count the tall peaks or deep scratches.

Roughness Depth (Rz). Averages the 5 deepest valleys & 5 tallest peaks within sample length. Gives you a better sense of how surface feels.

Trace Roughness (Rt) measures distance from the highest peak to the lowest valley in a trace. Measures how far from the highest peak to the lowest valley there is in that trace. Use this when even one defect will ruin a seal.

Root Mean Square (RMS). Squares the deviation first then averages it. It is usually around eleven percent bigger than Ra on machined profile. None of these are incorrect. Each answer a different question regarding surface topography.

These numbers vary based off each process. Because of their sharp peaks, for example, the Rz-to-Ra ratio for a ground surface will be greater then for a turned surface. Deep valleys created in honing raise Rz, yet Ra remain moderate. Plateauing lapped surfaces once more compress the Rz-to-Ra ratio.

The material also matters. Graphite flakes present in cast iron increase surface porosity and tend to widen Ra versus Rt separation. Aluminum, however, shears cleanly and behaves more consistanty. Also, the cutoff length selected on profilometer is important. A shorter cutoff disregards waviness included by a longer cutoff, changing all derived values.

There is no single multiplier that works for every part. To know what Ra value to go after, you have to understand the process that formed the surface. What type of material is it? Who is inspecting it and how? For example, a cosmetic cover can have same Ra target as a bearing journal. Yet they behaves differently at their peaks and valleys.

This is why calculator makes those tweaks on your behalf. There is no way to know if my shaft with a 1.6 µm Ra would read more like 7 µm or 11 µm Rz. These are the predictable errors.

The engineers make a callout in an old drawing and just copy it over, not even thinking to check the process. The inspectors fail to verify cutoff length in the spec. It doesn’t match what the supplier has. The purchasing person sends them a print reading: Ra 0.8 maximum, with no mention of peak height or lay direction. Surprise! Lapped parts don’t pass a leak test.

Failures of math? No. Failures to speak same language in the supply chain?

Real surfaces aren’t neat; they have profile shapes, tolerance bands, and cutoffs. Polishing can produce rounded peaks while turning can create sharper feed marks that behaves differently under load. Parts concerned with fatigue will be more sensitive to highest stress riser rather than average roughness. Use function over one magic number. It makes it all less mysterious and more helpful.

Roughing up the surface isn’t an exercise in reaching a certain number. Roughing up the surface is a matter of picking the proper texture for the task at hand. Make sure both metrologist and machinist are measuring the same thing. You should of gotten this part correct, then the calculator will be a bridge between the drawing board and the shop floor.
