How Much Pea Shingle Do I Need Calculator

How Much Pea Shingle Do I Need Calculator

Estimate pea shingle or pea gravel for garden paths, borders, drives, soakaway trenches, and drainage layers using shape, depth, density, compaction, edging loss, bags, tonnes, and yards.

📌Project Presets

⚙Pea Shingle Inputs

Use for pipe bedding, soakaway fill, or a separate drainage layer under a decorative cover.

Adjust if your supplier lists a loose bulk density or tonne bag volume.

Order Volume
0.00
cubic yards
Bulk Weight
0.00
tons / tonnes
Small Bags
0
bags
Coverage Area
0
sq ft
Drainage Portion
0.00
yd³ in extra layer
Bulk Bags
0
bulk bags

🧪Aggregate Spec Grid

10 mm
Nominal Size
1.30
tons per yd³
2 in
Typical Depth
Good
Drainage

📊Pea Shingle Reference Tables

Project Typical Finished Depth Compaction Allowance Edging Loss
Garden path 2 to 3 in / 50 to 75 mm 3 to 8% 5 to 10%
Decorative border 1.5 to 2 in / 40 to 50 mm 0 to 5% 5 to 8%
Driveway top dressing 3 to 4 in / 75 to 100 mm 5 to 10% 8 to 12%
French drain layer 4 to 8 in / 100 to 200 mm 5 to 10% 10 to 15%
Soakaway trench fill 8 to 18 in / 200 to 450 mm 5 to 12% 10 to 18%
Pea Shingle Type Nominal Size Loose Bulk Density Best Use
10 mm washed pea shingle 3/8 in / 10 mm 1.25 to 1.35 tons per yd³ Paths, beds, pipe bedding
20 mm washed pea gravel 3/4 in / 20 mm 1.20 to 1.32 tons per yd³ Drainage layers and borders
Mixed 10 to 20 mm pea gravel 3/8 to 3/4 in 1.28 to 1.38 tons per yd³ Walkways and general landscaping
Rounded decorative gravel 10 to 14 mm 1.22 to 1.32 tons per yd³ Beds, courtyards, light foot traffic
Angular drainage shingle 14 to 20 mm 1.30 to 1.42 tons per yd³ Drains, soakaways, wet areas
Bag or Bulk Unit Common Weight Approx Volume at 1.30 t/yd³ Use in Calculator
Small US bag 40 to 50 lb 0.57 to 0.71 ft³ Set bag weight to the label weight
Large US bag 80 lb About 1.03 ft³ Useful for small borders and repairs
UK small bag 20 to 25 kg 0.012 to 0.015 m³ Switch to metric and enter kg
Bulk bag 0.75 to 0.90 tonne 0.58 to 0.69 m³ Use bulk bag allowance for count
Shape Area Formula Good For Measurement Note
Rectangle Length × width Straight paths, strips, beds Measure inside fixed edging
Circle 3.1416 × radius² Tree rings and round seating pads Use the full outside diameter
Triangle Base × height / 2 Tapered corners and wedge beds Use length as the height
Known area Entered area Mapped or measured landscapes Enter square feet or square meters

💡Quantity Tips

Depth tip: Use the finished depth you want after light settling. For decorative pea shingle, a shallow layer can reveal membrane or soil; for drainage, depth usually matters more than surface appearance.
Ordering tip: Keep edging loss separate from compaction. Compaction covers settlement into voids, while edging loss covers curves, raking, spillage, and trimming around beds or drains.
Drainage note: keep pea shingle clean and free draining around pipes, soakaways, and wall skirts. Confirm trench dimensions and local drainage requirements before ordering material.

From far away, the garden path seem fine. Up-close? Not so much: The pea shingle has silted onto the lawn, gone thin in spots, vanished around the edges. You ordered what seemed like plenty to do the job…on paper. But didn’t factor in how gravel will spreads and settle. And hide in the shade cast by your edging.

Focus on depth and what is lost, rather then how much you think you need. That’s where most DIY endeavors derail.

How to Calculate the Right Amount of Gravel

It’s easy enough: You input your dimensions into the calculator above, and it does the math, avoiding any cubic conversions on your part. But that’s where the work begins: figuring out what these numbers mean for your weekend.

First up is depth, the bigger variable. Two inches might sound like a lot…until you stretch it across an area. It is also primarily decorative and is something to look at when it are used as a border or for lightly used areas. For heavier use (like a driveway or drainage trench), plan on four inches or greater.

Moving all this stuff are the time commitment here; it isn’t simply about the size of the stone, but how much of it there is. They forget about part that costs money: the compaction allowance. Because gravel consists of rounded stones with voids in between, those voids gets filled in when you walk on them; or when rainfall compacts the layer. Order just enough stone to fill the theoretical void space? Within a month, path will appear thin. It’s a matter of physics; add five to ten percent for settlement, not optional.

Why does the tool ask for such a percentage? Loose stone shrinks. Skip it and what you buy is a thin veneer (not a stable surface).

Or then there’s the edging loss. The waste that isn’t represented on the blueprint. Rake gravel around that rounded-up flower bed or against a timber edge, and some spills out and gets kicked back onto the lawn. That same thing happens along a curved path instead of a straight one because you won’t have straight edges where the rake can stop neatly. Tweak the loss factor in the calculator, so if your path is a meandering ribbon through the garden, bump up that percentage; if it’s a straight line from shed to shed, go easy on the loss number. It seems like such a tiny tweak but on a big area, that additional ten percent makes all the difference between getting the job done or heading back to the hardware store.

Not all pea shingle are the same, and neither is density. Angular stone will pack down tighter (and may weigh more per cubic yard), while washed stone is cleaner but can be lighter. Change this input in the tool if your supplier has a differnt bulk density. The tool uses an average standard, but there can be variation by local quarries. You could end up paying for volume, when it’s realy weight, or vice versa; it’s a subtle trap, so always check the bag, or ask skip driver.

Tonnes do proper jobs; bags are for little ones. You don’t buy eighty bags just because calculator says so. Instead, you order a bulk bag or a tipper truck if the answer is eight tonnes. From then on, it becomes weight rather than number of items in the maths. Heavy things behave differently and stays in place better. It also hurts more when you drop it on your toe.

But bagged or bulk isn’t purely a price issue. Consider whether you’ll get a tonne bag through the gate, or carry eighty bags over the lawn unscathed. Your back decides how it will arrive; the figures determine what arrives.

Put down a thick layer first. Top up the curves. Buy a bit more than the math tells you. It is better to have some excess to top up instead of having a trail fade out. You should of bought extra so it doesnt look thin later. It’ll all settle down. The edges will round off. But as long as you’ve got the right volume, it will look like part of the design.

That’s what this should be: a real path, not just a hole covered by something.
