Fan Static Pressure Calculator

Fan Static Pressure Calculator

Estimate fan system resistance from duct friction, fittings, filter, coil, grille, hood losses, target CFM, altitude, and a simple fan curve margin check.

1Fan Presets

Pick a realistic starting point, then adjust the duct and component details to match the actual installation.

2System Inputs
Airflow at the operating point you want the fan to hold.
Percent of the run that behaves like flex, sagged, corrugated, or disturbed duct.
Use loaded filter drop when choosing a fan.
3Results
0.00 Required static pressure

Includes duct, fittings, components, altitude, and selected design margin.

0.00 Fan available pressure

Estimated from the selected fan curve at the target CFM.

0.00 Fan curve margin

Positive margin means the preset fan can cover the calculated resistance.

0 Duct velocity

Air speed through the selected duct area.

0.00 Duct and fitting loss

Straight length plus equivalent length from elbows, tees, and dampers.

OK Operating flag

Quick check for pressure margin and practical duct velocity.

4Fan and System Grid

The system curve estimates pressure at nearby airflow points. Fan pressure is estimated from the selected preset curve and derated for altitude.

Airflow point Estimated CFM System SP Fan SP Margin
5Selected Fan Spec Grid
6Fan Preset Reference
Preset Typical free air Approx max static Good use
Bathroom exhaust fan110 CFM0.45 in w.g.Short 4 to 6 in residential exhaust
Residential range hood blower450 CFM0.80 in w.g.Kitchen exhaust with wall or roof cap
4 in mixed-flow inline fan205 CFM1.30 in w.g.Small grow tent, booster, cabinet exhaust
6 in mixed-flow inline fan402 CFM1.60 in w.g.Medium inline ventilation and carbon filter
8 in mixed-flow inline fan807 CFM1.80 in w.g.Larger inline runs with filters and hoods
Residential PSC furnace blower1200 CFM0.80 in w.g.Typical forced-air cabinet and duct system
Residential ECM furnace blower1400 CFM1.00 in w.g.Higher static residential air handler
Commercial roof exhaust fan2500 CFM1.25 in w.g.Longer exhaust with curb, filters, or hood
1.5 hp dust collector blower1100 CFM9.00 in w.g.High resistance chips and dust collection
Inline radon fan170 CFM2.00 in w.g.Small pipe, soil gas, and high static service
7Duct and Fitting Reference
Duct or fitting Model value Pressure effect Planning note
Clean galvanized steelRoughness 0.0005 ftBaselineGood default for rigid sheet metal
Spiral round ductRoughness 0.0003 ftLow frictionOften smoother and rounder than field-built duct
Tight flexible ductLength factor 1.55Medium frictionWorks best stretched, supported, and short
Sagging flexible ductLength factor 2.60High frictionSags and compression can dominate the pressure budget
One 90 degree elbow30 diametersEquivalent lengthTight elbows may be worse than this estimate
Branch tee or wye60 diametersEquivalent lengthUse balancing data for critical systems
Damper or backdraft12 diametersEquivalent lengthClosed or spring-loaded devices can add more
8Component Loss Reference
Component Typical low drop Typical high drop What to verify
Residential filter0.08 in w.g.0.40 in w.g.Use the filter chart at the planned airflow
MERV 13 filter or rack0.18 in w.g.0.70 in w.g.Loaded final resistance can be much higher
Cooling coil0.15 in w.g.0.45 in w.g.Wet coil tables are more conservative
Heat recovery core0.20 in w.g.0.90 in w.g.Check both supply and exhaust sides
Grille or register0.03 in w.g.0.25 in w.g.Face velocity and free area matter
Exterior hood or cap0.05 in w.g.0.50 in w.g.Screens, louvers, and bird guards load quickly
9Velocity and Altitude Guide
Use case Common velocity range Static pressure concern Design note
Quiet residential supply500 to 800 FPMNoise before frictionUse larger ducts for bedrooms and quiet spaces
Residential return300 to 700 FPMFilter and grille lossLow return velocity helps blower performance
General exhaust900 to 1800 FPMHood and terminationBalance capture velocity against noise
Commercial duct1200 to 2500 FPMFriction and fittingsCheck acoustic criteria for occupied zones
Dust collection branch3500 to 4500 FPMHigh static loadVelocity is needed to keep chips moving
5000 ft altitudeAbout 83% densityFan pressure deratesFan in w.g. capability falls with air density
10Practical Tips
Use measured component data. Filter, coil, silencer, hood, and grille losses are often larger than the duct friction. When possible, enter manufacturer pressure drop at the target airflow rather than a generic allowance.
Do not size on free-air CFM. A fan rated 400 CFM free air may deliver far less once duct, elbows, filters, altitude, and outlet restrictions are added. Use the fan curve margin result before selecting equipment.
Static pressure estimates are planning aids. Verify final HVAC, exhaust, combustion, radon, and dust collection systems against applicable codes, manufacturer fan curves, noise limits, and safety requirements before installation.
'; html += '
' + fmt(data.frictionFactor, 3) + 'Friction factor

' + duct.name + '

'; byId('fspSpecGrid').innerHTML = html; } function makeBreakRow(label, value) { return '
' + label + '' + value + '
'; } function velocityFlag(system, velocity) { if (velocity < system.low * 0.75) { return 'Low velocity'; } if (velocity > system.high * 1.25) { return 'High velocity'; } if (velocity > system.high) { return 'Near high'; } if (velocity < system.low) { return 'Near low'; } return 'OK'; } function buildCurveRows(inputs, fan) { var points = [0.60, 0.80, 1.00, 1.20, 1.40]; var html = ''; var i; for (i = 0; i < points.length; i++) { var cfm = inputs.targetCfm * points[i]; var calc = computeAtCfm(cfm, inputs); var fanSp = fanStaticAt(fan, cfm, inputs.densityRatio); var margin = fanSp - calc.totalBeforeMargin; html += '' + fmt(points[i] * 100, 0) + '% of target' + fmtWhole(cfm) + '' + fmt(calc.totalBeforeMargin, 2) + ' in w.g.' + fmt(fanSp, 2) + ' in w.g.' + fmt(margin, 2) + ' in w.g.'; } byId('fspCurveRows').innerHTML = html; } function buildStatus(fan, system, data, fanSp, marginSp, velocityStatus) { var status = ''; if (marginSp >= 0.15) { status += 'Fan curve check: The selected preset has comfortable static pressure margin at the target CFM. '; } else if (marginSp >= 0) { status += 'Fan curve check: The selected preset barely clears the calculated pressure. Confirm the real fan curve and loaded filter drop. '; } else { status += 'Fan curve check: The selected preset is short by ' + fmt(Math.abs(marginSp), 2) + ' in w.g. at target airflow. Choose a stronger fan, reduce losses, or lower CFM. '; } if (velocityStatus === 'OK') { status += 'Velocity: ' + fmtWhole(data.velocity) + ' FPM sits inside the usual range for ' + system.name + '.'; } else { status += 'Velocity: ' + fmtWhole(data.velocity) + ' FPM is flagged as ' + velocityStatus.toLowerCase() + ' for ' + system.name + '.'; } if (data.filterLoss > 0.45) { status += ' Filter resistance is a major part of the pressure budget.'; } return status; } window.fspCalculate = function() { var fan = fanPresets[byId('fspFan').value] || fanPresets.inline6; var duct = ductProfiles[byId('fspDuctMaterial').value] || ductProfiles.galv; var system = systemVelocity[byId('fspSystemType').value] || systemVelocity.exhaust; var geometry = getGeometry(); var altitudeFt = unitAltitudeToFt(readNumber('fspAltitude', 0)); var densityRatio = densityRatioAtAltitude(altitudeFt); var inputs = { fan:fan, duct:duct, system:system, geometry:geometry, targetCfm:Math.max(1, readNumber('fspCfm', 400)), lengthFt:Math.max(0, unitLengthToFt(readNumber('fspLength', 60))), flexPct:Math.max(0, Math.min(100, readNumber('fspFlex', 0))), elbows90:Math.max(0, readNumber('fspElbows90', 0)), elbows45:Math.max(0, readNumber('fspElbows45', 0)), tees:Math.max(0, readNumber('fspTees', 0)), dampers:Math.max(0, readNumber('fspDampers', 0)), filterDrop:Math.max(0, readNumber('fspFilter', 0)), filterFactor:parseFloat(byId('fspFilterState').value), coilDrop:Math.max(0, readNumber('fspCoil', 0)), grilleDrop:Math.max(0, readNumber('fspGrille', 0)), hoodDrop:Math.max(0, readNumber('fspHood', 0)), altitudeFt:altitudeFt, densityRatio:densityRatio, margin:parseFloat(byId('fspMargin').value) }; var data = computeAtCfm(inputs.targetCfm, inputs); var fanSp = fanStaticAt(fan, inputs.targetCfm, densityRatio); var marginSp = fanSp - data.totalWithMargin; var vFlag = velocityFlag(system, data.velocity); var operatingFlag = 'OK'; if (marginSp < 0) { operatingFlag = 'Short'; } else if (vFlag !== 'OK') { operatingFlag = 'Check'; } byId('fspTotalSp').innerHTML = fmt(data.totalWithMargin, 2) + ' in'; byId('fspFanSp').innerHTML = fmt(fanSp, 2) + ' in'; byId('fspMarginOut').innerHTML = fmt(marginSp, 2) + ' in'; byId('fspVelocity').innerHTML = fmtWhole(data.velocity); byId('fspDuctLoss').innerHTML = fmt(data.straightLoss + data.fittingLoss, 2) + ' in'; byId('fspAirflowScore').innerHTML = operatingFlag; byId('fspStatus').innerHTML = buildStatus(fan, system, data, fanSp, marginSp, vFlag); var breakdown = ''; breakdown += makeBreakRow('Target airflow and fan', fmtWhole(inputs.targetCfm) + ' CFM, ' + fan.name); breakdown += makeBreakRow('Duct geometry', geometry.display + ', area ' + fmt(geometry.area, 2) + ' sq ft'); breakdown += makeBreakRow('Air velocity and velocity pressure', fmtWhole(data.velocity) + ' FPM, VP ' + fmt(data.velocityPressure, 3) + ' in w.g.'); breakdown += makeBreakRow('Duct material model', duct.name + ', roughness ' + fmt(duct.rough, 4) + ' ft, length factor ' + fmt(duct.lenFactor, 2)); breakdown += makeBreakRow('Straight duct loss', fmt(data.straightLength, 1) + ' effective ft, ' + fmt(data.straightLoss, 3) + ' in w.g.'); breakdown += makeBreakRow('Fitting equivalent length', fmt(data.equivalentLength, 1) + ' ft, ' + fmt(data.fittingLoss, 3) + ' in w.g.'); breakdown += makeBreakRow('Filter pressure', fmt(inputs.filterDrop, 2) + ' x ' + fmt(inputs.filterFactor, 2) + ' = ' + fmt(data.filterLoss, 3) + ' in w.g.'); breakdown += makeBreakRow('Coil, grille, hood losses', fmt(data.coilLoss, 3) + ' + ' + fmt(data.grilleLoss, 3) + ' + ' + fmt(data.hoodLoss, 3) + ' = ' + fmt(data.coilLoss + data.grilleLoss + data.hoodLoss, 3) + ' in w.g.'); breakdown += makeBreakRow('Altitude density factor', fmt(inputs.altitudeFt, 0) + ' ft, air density ' + fmt(densityRatio * 100, 1) + '% of sea level'); breakdown += makeBreakRow('Total before margin', fmt(data.totalBeforeMargin, 3) + ' in w.g.'); breakdown += makeBreakRow('Design margin applied', fmt(inputs.margin * 100, 0) + '% gives ' + fmt(data.totalWithMargin, 3) + ' in w.g. required'); breakdown += makeBreakRow('Fan curve result', fmt(fanSp, 3) + ' in w.g. available, margin ' + fmt(marginSp, 3) + ' in w.g.'); byId('fspBreakdown').innerHTML = breakdown; buildSpecGrid(fan, duct, data); buildCurveRows(inputs, fan); byId('fspResults').className = 'fsp-section fsp-results fsp-active'; byId('fspCurveSection').className = 'fsp-section fsp-results fsp-active'; lastInputs = inputs; }; window.fspToggleShape(); setUnitLabels(); window.fspCalculate(); })();

To select the fan that is apropriate for a ventilation or HVAC system, you need to understand the amount of resistances that the air will encounter. Static pressure are the force that resists airflow through every component of the system. If the fan selected for installation cant overcome the static pressure of the system, the airflow will be insufficient to provide adequate mixing or exhaust air from the space.

The fan static pressure calculator will help you to determine the static pressure of the system by entering the informations regarding the system components. The material out of which the ducts is constructed will affect the static pressure of the system. Air will encounter friction as it move through the ducts.

How to Use a Fan Static Pressure Calculator

For example, flexible ducts will create more friction than ducts made of metal. The calculator accounts for this by using a length factor that accounts for the length and material of the ducts. A long run of flexible ducts will have a higher length factor than an equivalent length of metal ducts.

Each fitting within the system will create some static pressure. Elbows, tees and other fittings will create turbulence in the system that raises the static pressure within the system. The calculator treats each of these component as an equivalent length of duct.

Dampers and backdraft preventers will also create some static pressure within the system. While a small number of dampers will not significantly impact static pressure, installing numerous dampers will increase static pressure significant. Another major component of static pressure are the air filters and coils.

Air filters will create static pressure within the system. The pressure drop across a clean filter is small but the resistance of a loaded filter will double the static pressure of a clean filter. It is essential to use a loading factor for fans calculations to account for the loaded filter.

Additionally, the coils within the system will also add to the static pressure of the system. If the cooling coils becomes wet with condensation of the moist air within the system, the static pressure will be higher than that of dry heating coils. You must enter the static pressure of the loaded cooling coils into the fan static pressure calculator.

The altitude at which the fan will be installed will impact the performance of that fan. As the altitude increases, the air pressure decrease. Fans will produce less static pressure at 5,000 feet above sea level then they will at sea level.

The fan static pressure calculator will account for the difference in air densities by using a density ratio that accounts for the difference in static pressures at different altitudes. Using a fan that is rated at sea level in the mountains will not provide the static pressure required by the system. The calculator will provide two main readings for the fan static pressure calculations.

The static pressure required by the system and the margin for the fan curve provide valuable informations to the designer. If the fan curve provides a small margin for error the fan is close to working at its limits. A larger margin allow for variations within the system such as dirty air filters.

The velocity of the air within the system is also an important parameter. If the velocity of the air is too low within the system, it may not function proper in relation to the tasks that it must accomplish. Additionally, if the velocity within the ducts is too high it will create excessive noise within the system.

The fan static pressure calculator will show if the velocity is outside of the normal range. Common errors when installing fans within HVAC systems are treating the specifications of the fan as a guarantee of performance. Fans may be rated at 400 cubic feet per minute of free air yet will move significantly less air when the static pressure of the system is accounted for.

The fan static pressure calculator will help the designer to understand the difference between the rating of the fan and the performance of the fan. Another common error is to use the static pressure of a clean air filter rather than using the static pressure of a loaded air filter. Using the static pressure of a clean filter will result in a fan that does not provide enough airflow to the system.

The fan static pressure calculator will help to graph the system static pressure curve and fan static pressure curve. The interaction of these two graphs will provide information to the designer regarding the performance of the fan under the current conditions within the system and under potential changes to the system. For instance, if the fan barely provides the static pressure required by the system, should the filter become loaded, the fan will not be able to meet the requirements of the system.

Static pressure is a value that defines the difference between a fan system that meets the requirements of the facility and one that do not. By entering the dimensions of the ducts, the length and type of the fittings and the static pressure of each component of the system the designer gains an understanding of the static pressure that the fan will encounter. Additionally the margin for the fan curve provides information regarding if the purchased fan has the necessary reserve in its performance to handle these static pressure requirement.
